I. Introduction

In modern cosmetics production, precision and efficiency are paramount. The cream labeling machine revolutionizes packaging by automating label application with ±1mm accuracy, handling 50-120 vials/min, and adapting to containers of 25-120mm diameter. This guide combines technical specifications with emotional insights to empower your production line.

II. Operation Guide

1.Setup & Calibration

• Adjust suction cup position via N/M controls to meet X=1-3mm, Y=1-3mm tolerance. Misalignment risks collision with stripping plate E.

• Install label roll with inner diameter φ76mm, outer diameter max φ350mm. Thread labels through the dispenser, ensuring tension alignment.

2.Power & Safety

• Use AC220V/50-60Hz power supply. Disconnect immediately during maintenance. Avoid alcohol/acid cleaning agents.

• Power consumption: 1.0KW. Emergency stop button halts operation if foreign objects detected.

3.Operation Flow

• Start machine, observe label extension length. Adjust speed via touchscreen PLC (50-120 vials/min).

• For soft plastic tubes (15-60mm diameter), customize labeling height up to 130mm.

III. Application Scope

• Industries Covered

Cosmetics, pharmaceuticals, food & beverage, cleaning products. Handles tubes, bottles, jars from 20mm to 300mm height.

• Customization

SS304 stainless steel construction. Conveyor width customizable to match sample bottle diameter. Supports barcode/QR code labeling integration.

IV. Advantages & Emotional Benefits

1.Efficiency Boost

• 60% faster than manual labeling. A cosmetics brand reported 30% production increase post-automation.

2.Precision & Compliance

• ±1mm accuracy ensures consistent branding. Complies with FDA/ISO packaging standards.

3.Cost Savings

• Reduces labor costs by 40%. Minimal downtime with self-diagnostic PLC system.

4.Brand Enhancement

• Flawless label application enhances product aesthetics. 80% of consumers trust automated packaging for quality assurance.

V. Maintenance & Troubleshooting

• Regular Care

Clean with dry cloth weekly. Lubricate moving parts monthly. Replace worn suction cups annually.

• Common Issues

Mislabeled tags? Check sensor alignment. Wrinkled labels? Adjust tension roller pressure.

VI. Conclusion

The cream labeling machine isn’t just equipment—it’s a strategic investment in quality, efficiency, and brand loyalty.

With data-driven precision and user-friendly design, it transforms production from labor-intensive to intelligent.

Embrace automation, and watch your products shine on shelves with impeccable labeling.

Technical Specifications:‌

The following parameters apply to standard models. Customized solutions are available for special requirements or additional functions.

LABELING ACCURACY：±1 mm (subject to the product's overall dimensions and flatness)

Labeling Speed（pcs/min）：40～120pcs/min(Related to Bottle and Label Dimensions)

VOLTAGE ：AC220V 50HZ

TOTAL POWER：≤1 kW for 1 hour

Production output:1-50 bottles/min(speed adjustable subject to product diameter size)

Adaptable Product Range:  Φ20-Ф100 mm diameter (Special fabrication required for non-standard sizes)

Qualification Rate: ≥99% (or higher)

Dimensions:‌ 2000×1050×1350 mm (Length × Width × Height)

Net Weight:‌ ≤200 kg

Primary Applications:‌

• ‌Compatible Labels:‌ Pressure-sensitive labels, pressure-sensitive films, digital supervision codes, barcodes, etc.


• Suitable Products:‌ Products requiring label or film application onto curved/cylindrical surfaces.

• Target Industries:‌ Widely used in food, pharmaceutical, cosmetics, household chemicals, electronics, hardware, and plastic industries.

• Typical Applications:‌ Labeling round PET bottles, plastic bottles, food cans, etc.

Dongguan Dawei Machinery Equipment Co., Ltd.‌

         Located in Dongguan, China – a dynamic manufacturing hub in Guangdong Province – we are a high-tech enterprise specializing in R&D, production, sales, and service of intelligent packaging equipment. We deliver efficient, precision packaging line solutions worldwide, empowering industrial automation upgrades.

Core Product Lines:‌

• Labeling Machines:‌ Self-adhesive, round-container, flat-surface & irregular-profile models

• ‌Sleeve Labelers:‌ Heat-shrink film sleeve labeling systems

• ‌Fillers:‌ Liquid / Paste / Powder filling machines

• ‌Cappers:‌ Rotary capping equipment

• ‌Full-line customization‌ for food, pharmaceuticals, daily chemicals, electronics & more

Serving 100+ enterprises across beverage, pharma, and FMCG sectors. Products exported to Southeast Asia, Middle East, and Africa markets with established partnerships with renowned brands.

Service Commitment:‌

End-to-end support including:

• Needs analysis & solution design

• Installation & commissioning

• Post-installation maintenance

• Custom engineering

• 24/7 emergency support

• Operator training

• Ensuring operational stability and productivity
